Electric car charging station 22 kW h766_03

Regular Price €1,644.75 Special Price
€1,425.45 VAT excl.
In stock
SKU
h766_03

Charging box for electric vehicles in fiberglass-reinforced polycarbonate. Type 2 three-phase socket. Power: max. 32A (22 kW).

The electric car charging station is a tool to be installed on the wall in public places, to allow drivers and owners of electric vehicles to charge them. This model is entirely made in Italy and is a three-phase version with a maximum power of 32A (22 kW). Equipped with a Type 2 socket with shutter, cover, and anti-extraction interlock. Quickly installable, it has a simplified visual LED interface and a Type B differential. The energy meter is MID certified. The product complies with current regulations.



Technical features:

  • Material: glass-fiber reinforced polycarbonate
  • Dimensions: W. 360 x D. 150 x H. 360 mm
  • Three-phase version with maximum power output 32A (22 kW)
  • Type 2 socket with one-hand insertion
  • Interlock, cover and shutter
  • Type B differential
  • Overcurrent and short-circuit protection
  • MID certified energy measurement
  • Visual LED interface
  • Control system with detection of correct cable insertion, charging status signaling, socket availability signaling
  • Automatic charging resumption following power supply interruption
  • Nominal voltage: 400Vac
  • Protection degree: IP55
  • Frequency: 50-60 Hz
  • Insulation voltage: 400Vac
  • Operating temperature: -25°C  +40°C
  • Color: RAL 7000
  • Mounting: wall or pole (not included)
  • 1 anti-vandal start-stop charging button
  • Multi-color LED for socket status signaling
  • USB port (internal)
  • Charging cable is not included
  • Compliant with current regulations
  • Made in Italy







* Upon request and subject to quotation, it is possible to install the paid service for charging electric vehicles.

* Image purely indicative.

More Information
Height in millimetres 360.00
Length in millimetres 360.00
Depth in millimetres 150.00

Electric car charging station 22 kW h766_03
