The Care home nursing bed H582_240 is intended for the care of individuals hospitalized for health reasons in healthcare and welfare institutions or in a home setting. It is designed to accommodate patients with high weight requirements, offering an extraordinary capacity of up to 325 kg, with a safe working load of 390 kg. For this reason, it represents an ideal solution for nursing homes, healthcare facilities, and home care, where patient well-being and operational practicality are essential elements.

The bed is equipped with four independent motors, designed to ensure precise and smooth adjustments: two motors manage the vertical elevation, while the other two move the backrest and legs. This versatility allows the bed to be adapted to the different needs of the patient, promoting a correct and comfortable posture during the hospital stay and daily care activities. The robust tubular steel structure ensures stability and durability over time even under intensive use conditions, while the painted steel mattress platform completes an assembly designed for solidity and functionality.

From an aesthetic point of view, the wooden headboard and footboard give the bed a warm and welcoming appearance, harmoniously integrating even into home environments. In emergency situations, the integrated battery lowering system ensures the restoration of the horizontal position even in the event of a power failure, guaranteeing continuity and safety. The product complies with the UNI CEI EN 60601-2-52 standard and is indicated for Application Environment Type 3 and 4 according to EN 60601-2-52, with complete technical specifications including mattress platform height 27–70 cm, head lift up to 70°, leg lift up to 30°, footrest -25/0° in 3 ratchet steps, and tilt up to 15°.

Purchase the H582_240 care home nursing bed now or request a quote for multiple supplies for healthcare facilities, nursing homes, and home care.

Technical characteristics:

• Intended use: nursing care in healthcare/welfare institutions and home setting

• Compliance: UNI CEI EN 60601-2-52

• Application environment: Type 3 and 4 (EN 60601-2-52 standard)

• Maximum patient weight: 325 kg

• Safe working load: 390 kg

• Motorization: 4 independent motors (2 vertical elevation + 2 backrest and leg movement)

• Emergency system: lowering with integrated battery for horizontal position restoration

• External dimensions: 278 x 134 x 85–128h cm

• Mattress platform dimensions: 200 x 120 cm

• Maximum height at the ends: 128 cm

• Minimum frame height: 27 cm

• Mattress platform height: 27–70 cm

• Maximum head lift angle: 70°

• Maximum leg lift angle: 30°

• Footrest angle: -25/0° (3 ratchet steps)

• Tilt angle: 15°

• Total weight: 175 kg

• Electric kit weight: 24/26 kg

• Force required to operate controls: 5 N

• Wheels: 10 cm

• Power supply: 230V Vac 50/60 Hz Max 2.1A

• Control unit output voltage: 24V Dc

• Protection class: IP X4

• Insulation class: Class 2

• Applied part: Type B

• Noise level: < 53 dB at 1 mt distance

• Main materials - mattress platform: painted steel

• Main materials - structure and side rails: wood

• Supporting structure: tubular steel (as per product description)

User benefits:

• Supports: bariatric patients thanks to a maximum weight of 325 kg and a safe load of 390 kg.

• Adjustments: precise and smooth with 4 independent motors to adapt posture and comfort.

• Greater: safety in emergency with an integrated battery for return to horizontal position.

• Stability: and durability thanks to the tubular steel structure.

• Integration: more harmonious even at home with a wooden headboard and footboard.

FAQ:

1. Is the H582_240 bed suitable for healthcare facilities and home care?
   Yes, it is intended for nursing care in healthcare and welfare institutions and can also be used in a home setting.

2. What is the maximum capacity of the bed?
   The maximum patient weight supported is 325 kg, with a safe working load of 390 kg.

3. What happens if there is a power failure?
   The bed integrates a battery lowering system that allows for the restoration of the horizontal position even without power.

4. What adjustments does it allow and what are the maximum angles?
   It allows vertical elevation and backrest/leg movement with 4 motors. Angles: head lift 70°, leg lift 30°, footrest -25/0° (3 ratchet steps), tilt 15°.

5. Does the product comply with specific standards for medical beds?
   Yes, it complies with UNI CEI EN 60601-2-52 and is indicated for Application Environment Type 3 and 4.

Short buying guide:

When choosing a nursing bed for patients with high weight requirements, the first parameter to evaluate is the capacity: in this case, the maximum patient weight of 325 kg and the safe working load of 390 kg are decisive for reliable use in facilities and at home. Immediately after, consider the quality of the adjustments: a 4 independent motor system allows for more complete and smooth movements, useful for modulating elevation, backrest, and legs based on care needs. The mattress platform height range (27–70 cm) also affects practicality for the operator and patient comfort during daily maneuvers. In the healthcare sector, it is important to anticipate emergencies: the presence of the integrated battery that returns the bed to a horizontal position in the event of a blackout increases operational safety. Finally, always check regulatory compliance: UNI CEI EN 60601-2-52 and the Type 3 and 4 indication are fundamental requirements for use in care contexts.

H582_240 nursing bed, high capacity nursing bed 325 kg, bariatric electric bed 4 motors, nursing home bed, healthcare facility bed, high capacity home care bed, UNI CEI EN 60601-2-52 bed, IPX4 medical bed, bed with emergency battery, 200x120 nursing bed.

*Images purely indicative.
