This folding hospital bed is a professional solution designed for home and clinical care, aimed at combining structural robustness with maximum logistical efficiency. The structure is foldable in two sections, a fundamental feature to facilitate transport and storage in small spaces. The adjustment of the backrest inclination occurs via a removable chrome crank, equipped with an end-of-travel stop to ensure maximum operational safety and prevent mechanical damage.
Technical features
Headboard and footboard: made of white painted steel with cream-colored MDF wood protective panels.
Bed base and frame: structure in tubular steel with electro-welded rod and transverse support bars.
Adjustment mechanism: manual inclination of the backrest from 0° to 85° (± 5°) via crank.
Portability: two-part folding frame with removable crank.
Headboard and footboard dimensions: 92 x 85 cm (height calculated from the ground to the upper edge of the arch).
Open dimensions: 205 x 85 x 50 cm (height measured from the ground to the supporting structure).
Closed dimensions: 85 cm (W) x 22 cm (D) x 101 cm (H).
Net weight: 35 kg.
Maximum user weight: 135 kg.
Maximum supported load: 170 kg (including mattress and accessories).
ISO classification: 18.12.07.003.
Optional
Side rails: pair of folding side rails in white painted tubular steel. Equipped with steel spring hooks coated in transparent plastic, they allow folding without the need for removal from the frame. Dimensions: 44 x 200 cm. Weight: 5.5 kg each.
Image for illustrative purposes only
User benefits
Space optimization: the foldable structure allows the environment to be cleared when the bed is not in use, facilitating cleaning maneuvers and the room’s livability.
Adaptable postural comfort: the backrest adjustment up to 85° allows for correct positions for eating, reading, or respiratory relief.
Ease of movement: the two-block closing system drastically reduces bulk, allowing easy passage through narrow doors or loading onto standard vehicles.
Guaranteed mechanical safety: the crank with end-of-travel stop prevents over-extension of the mechanism, protecting the device’s integrity and the patient’s stability.
High structural resistance: the use of electro-welded steel ensures a capacity of up to 170 kg, offering rigid and reliable support over time.
Scope of application
The device is specifically indicated for home care and long-term care contexts where space is a limited resource. It is the ideal tool for patients with reduced mobility who require a variation in trunk inclination for clinical or comfort reasons. It also finds application in residential communities or temporary reception centers that require technical beds that can be easily stored after use.
Why choose it
This model represents the optimal balance point between a standard hospital bed and a portable aid. It is the correct choice when an ISO-certified healthcare station is needed that does not require a bulky fixed installation. The manual crank eliminates dependency on electricity, making it operational in any environment, while the electro-welded base offers superior stability compared to traditional slatted bases in intensive care contexts.
FAQ
What is the advantage of the electro-welded rod base compared to a spring or slat base?
The electro-welded base provides more rigid and uniform support, which is essential for the correct positioning of anti-decubitus mattresses and ensuring greater durability under constant loads without deformation.
Is a technician needed to close or open the bed?
No, the structure is designed to be easily folded and transported. The crank is manually removable without the use of specific tools, making the bed ready for use or storage in a few minutes.
What regulation does this hospital bed comply with?
The product is classified according to ISO code 18.12.07.003, which identifies manually adjustable beds intended to facilitate the care and recovery of people with disabilities or motor limitations.
