• Controlled handling: the low weight (7 kg) and ergonomic handle reduce operator fatigue during frequent transport within wards.
• Stationary stability: the 3-wheel convertible configuration prevents unwanted movement of the cylinder during patient care operations.
• Spatial adaptability: the switch from 2 to 3 wheels allows access to corridors, patient rooms, and tight spaces without compromising maneuverability.
• Reliable tightening: the two straps keep the cylinder fixed during transport, preventing risks of falling and damage to the delivery tube.
• Hygienic durability: the acrylic powder coating and the non-toxic rubber of the handle resist decontamination and hospital cleaning protocols.
• Multiple compatibility: the 100 kg capacity allows for the safe loading of steel cylinders of different sizes within the Ø160 range.

The cylinder holder is suitable for intensive care, emergency rooms, anesthesia, and operating rooms where medical oxygen is delivered from pressurized steel cylinders. It is also used in nursing facilities, hospices, and dialysis centers where frequent cylinder movement is required during shifts.

Usable in public and private hospital contexts, specialized clinics, and home care centers equipped with oxygen therapy systems. Ideal for environments with daily transport needs and access to limited spaces, where the trolley’s configurational versatility represents a significant operational advantage.

Choosing this cylinder holder is correct when the healthcare environment primarily uses oxygen cylinders with a diameter of Ø160 and requires a versatile transport system that adapts to variable spaces (narrow corridors, single rooms, complex wards). It is the ideal solution if staff need to alternate fast transport operations with safe positioning, and if the frequency of movement is such that ergonomics is a priority to reduce fatigue.

It also represents the correct choice in facilities that have adopted strict sanitization protocols, as the materials (non-toxic rubber, acrylic coating) guarantee compatibility with hospital decontamination processes. It is a prerequisite that the cylinders in use comply with the Ø160 standard and that the operating weight does not exceed 100 kg, limits that this trolley was sized to handle safely.

What cylinder diameter is the cylinder holder compatible with?

The cylinder holder is specifically designed for cylinders with a diameter of Ø160 mm. It is not suitable for cylinders with diameters smaller or larger than this standard. Always check the cylinder standard before purchasing.

What is the difference between the 2-wheel and 3-wheel configuration?

The 2-wheel configuration is optimal for rapid transport in limited spaces and narrow corridors, as the trolley is more compact and manageable. The 3-wheel configuration significantly increases stability during stationary operations and when the cylinder remains still next to the patient, preventing unwanted movements.

What are the overall dimensions and footprint?

The overall dimensions are H.1100 × D.325 × W.300 mm. The height of the rings varies from a minimum of 245 mm to a maximum of 500 mm, depending on the configuration and setup of the trolley. The base plate measures 195 × 180 mm.

Does the cylinder holder comply with medical safety regulations?

The trolley is built with materials suitable for the hospital environment (non-toxic rubber, acrylic powder coating) and is sized to support medical steel cylinders. However, it is important to verify with the supplier the compliance with specific national and local regulations regarding medical trolleys and compressed gas transport systems used in your facility.

How much does the cylinder holder weigh when empty?

The own weight of the trolley is 7 kg, a low weight that facilitates movement even for operators with less physical strength and allows for manual transport even in emergency situations.

How are the cylinders fixed to the trolley?

The cylinder is secured by means of 2 tightening straps that guarantee safe fastening during transport, preventing slipping and protecting the delivery fittings from mechanical damage.
