• Easy transport: the ergonomic push handles and the 4 rubber wheels reduce physical effort in the daily handling of cylinders on construction sites and professional environments.
• Cylinder safety: the plate raised to 490 mm height, the 3 cm containment edge, and the painted chain prevent tipping and accidental falls during transport.
• Structural durability: the electrowelded tubulars, plate, and hoops guarantee rigidity and resistance over time, even on irregular surfaces like stoneware, asphalt, and concrete.
• Adaptation to tight spaces: the compact dimensions (460 × 450 mm base) and the 430 mm distance between the handles allow for passage in corridors and compact work areas.
• Resistance to external conditions: the acrylic powder coating in white RAL 9010 protects against moisture and wear, reducing maintenance and deterioration over time.
• Versatile compatibility: the 190 × 190 mm support plate and the support for 160/190 mm cylinders ensure compatibility with standard 5/7 liter formats.

The trolley is suitable for professional and industrial environments where it is necessary to transport gas cylinders frequently and in an organized manner. It finds application in construction sites, technical laboratories, workshops, and warehouses where acetylene, argon, or other working gas cylinders must be moved on hard surfaces such as stoneware, asphalt, concrete, and resin floors.

It is used in contexts where cylinder safety is a priority and transport occurs in tight spaces or with frequent handling needs. It is particularly suitable for situations where the operator works alone and needs a practical solution that reduces physical fatigue and minimizes the risk of cylinder damage or accidents during handling.

Choose this trolley when you need to move gas cylinders in professional environments with daily frequency and when cylinder safety during transport is an operational requirement. It is the correct solution if you work on hard and irregular surfaces (construction sites, workshops, technical warehouses) and if the work spaces require easy passage and maneuvers in compact areas.

The choice is also appropriate when you want to reduce cylinder wear thanks to the raised plate and the containment system, or when you have operators who move cylinders alone and need ergonomic handles that limit physical fatigue. It is also suitable if you prefer a structure that is robust, durable over time and made with an electrowelding process, ensuring superior structural rigidity compared to simple bolting.

What is the difference compared to a trolley with the cylinder resting directly on the ground?

This trolley lifts the cylinder 490 mm from the ground, protecting it from impacts and floor wear. The raised plate reduces exposure to dirt and moisture, extends the life of the cylinder, and makes transport safer thanks to the 3 cm containment edge that prevents lateral sliding.

Is it compatible with all cylinder sizes?

The trolley is designed for cylinders with a diameter of 160/190 mm and a capacity of 5/7 liters. Before purchasing, check that your cylinders fall within these specifications. The support plate is 190 × 190 mm and is sized for these common standards.

Can I use it on non-flat surfaces like gravel or soil?

No. The 100 mm rubber wheels are optimized for hard and compact surfaces: stoneware, asphalt, concrete, and resin. On loose soil, gravel, or very irregular surfaces, the trolley could get stuck or lose stability. It is not recommended for uncontrolled outdoor use.

Which standard certifies this trolley?

The trolley complies with CE conformity, meeting European safety requirements for handling equipment. There is no specific additional UNI or EN type certification in the provided documentation.

What is the weight of the empty trolley and how much does it weigh in real-use conditions?

The trolley’s self-weight is approximately 13 kg. The maximum capacity is 60 kg, so the total weight with the cylinder must not exceed 73 kg. A full 5/7 liter cylinder weighs about 10-15 kg, therefore the overall load remains well within safety limits.

How is the cylinder kept secure during transport?

The cylinder is protected by three elements: the raised plate with a 3 cm containment edge that prevents lateral sliding, and the tubulars with a white painted chain at the top that lock it. This triple system ensures stability even during movements and changes of direction.
